Pos.No.
Pcs
Article-No.
Spare-
part
Description
47
1
9570-00010
DU-Socket MB 1415 (14x15) KS
48
1
2481-11010
Receiving-Down holder
49
1
8480-60001
Springy Pressure Piece K M8 HWN205S
50
1
2481-11005
x
Pressure Rod Top
51
1
8180-23004
x
Cylinder Pin 3m6x24 DIN6325
52
1
8481-11000
x
Pressure Pin No. 244
53
1
1481-11005
x
Tool Holding Device, complete
54
4
8481-11020
x
Hex Socket Countersunk Head Screw M5x20
DIN7991
55
1
2481-11025
Bridge
56
1
9200-01002
DU-Socket MB 0810
57
2
8480-25018
Hex Socket Screw M2x10 DIN912
58
1
2481-11020
Segment Board Holding Plate
59
6
8570-00022
Disk A3,2 DIN 125-St burnished
60
4
8333-10012
Hex Socket Screw M3x8 DIN912
61
14
8170-36002
Hex Nut M3 DIN934
62
6
8480-81039
Hex Socket Screw M5x12 DIN912
63
3
8332-59007
Hex Nut M5 DIN934
64
4
8170-36001
Hex. Lens Head Screw M3x10
65
6
8570-00021
Serrated washer A 3,7 DIN 6798
66
2
8480-99065
Hex Socket Countersunk Head Screw M3x12
DIN7991 (galvanized)
67
6
8550-00015
Hex Socket Countersunk Head Screw M3x8
DIN7991
68
1
8121-30002
Hex Socket Screw M5x20 DIN912
69
1
8480-15020
Serrated Washer A5,3 DIN 6798
70
2
8170-36005
Disk B5,3 DIN125-St burnished
71
1
8480-99014
Spring Ring DIN 127 - A6
72
2
5480-15001
Adhesive Label Protective Conductor 12,5mm
73
1
2481-11027
Flat Plug 3x6, 3x0,8 (grounding)
74
1
1481-11000
x
Housing complete
75
8
8481-02008
x
Hex. Lens Head Screw M5x12 (galvanized-blue)
76
1
5481-03007
x
Label "Release"
77
1
5480-81005
x
Adhesive Label: Warning Hand Injury
78
1
5480-23004
x
Adhesive Label: Withdraw mains plug
79
1
5481-11050
x
Adhesive Label: Key Switch
80
1
5481-11000
Identification Plate
All spare parts which are not marked with an „X“, are safety related parts or in connection with
safety related parts of the machine. The assembly should be made from WEZAG.
If the replacement of the safety related parts or parts, which are in connection with these safety
related parts is done by the end-user, every guarantee- and warranty claim expires. The
manufacturer excludes any kind of liability for accidents, which are caused of the incorrect
replacement.
