Wezag CS 300 - Parts List Electrtic; Accessories Overview for Re-Orders

BDA CS 300 – 06/15 – REV. B Page 84 / 84
15.4 Parts List Electrtic
Pos.No.
Pcs
Article Number
Spare Part
Description
1
1
8481-11001
X
Motor Doga 259
2
1
8481-11007
Limit Switch
3
1
8481-11006
Position Board
4
1
1481-11004
X
Control Board, complete
5
1
8481-11019
Jumper
6
1
8481-11009
Transformer MSE 96LP/59,7
7
1
8480-10038
Socket Connector Type 690
8
1
8481-11014
X
Set-up key switch
9
1
8481-11015
Switching Element – Key Switch
10
1
8481-11013
X
Main Filter with Switch
11
3
8480-10072
Fuse 5x20 6,3A slow blow DIN41662
12
1
8480-10026
Voltage Selector 2-pol.110/220V
13
2
8481-11005
Battery Compartment 2x Baby Type C
14
2
1481-11007
X
Main Pressure Button round
15
1
8481-11010
X
Release Button
16
1
8481-11011
Switching Element-Release Button
17
1
1881-11003
X
Display FT800 with Frame
All spare parts which are not marked with an „X“, are safety related parts or in connection with
safety related parts of the machine. The assembly should be made by WEZAG.
If the replacement of the safety related parts or parts, which are in connection with these safety
related parts is done by the end-user, every guarantee- and warranty claim expires. The
manufacturer excludes any kind of liability for accidents, which are caused of the incorrect
replacement.
15.5 Accessories overview for re-orders
Electric foot pedal with safety cover and connecting cable Order No.: 1480-23011
Power cable for EU (with protective contact) Order No.: 8480-10048
Power cable for 115 V (with protective contact) Order No.: 8480-23015
