BDA CS 300 – 06/15 – REV. B Page 62 / 84
6.2 Inserting the Batteries
INFORMATION
+ The electrical Crimping Machine CS 300 is not operable without inserted batteries or if the
batteries are empty.
+ Disconnect power supply.
+ Turn the battery compartments 1 under
the electric Crimping Machine CS 300 to
open them.
+ Insert the batteries (2 x 2 x 1,5V Baby
Cells Type C) one after another with the
negative pole pointing to the top.
+ Close battery compartments 1 by turning
them.
If the wrong batteries are inserted or if they
are inserted in the wrong way, the following
error prompt appears: 048111000x03
If the batteries are empty, the following error
prompt appears: 048111000x04
