70
WHILL Model C2/Ci2 User Manual
5
6.
Pull out the cable from the cable-threading hole on the
seat assembly and arm, then lower the arm.
Cable-threading
hole
Cable
7.
Remove the control pad.
Remove the screw on the outside of the control pad
with your hand.
Remove the control pad by sliding it outward.
Before removing the control pad, ensure that the
cable is removed from the clips. Do not pull it
forcefully. There is a risk of breaking the cable that
is connected to it.
Screw
8.
Remove the round unit at the head of the arm on which
the control pad is not attached.
Remove the screw on the outside of the round unit
at the head of the arm with your hand.
Remove the round unit at the head of the arm by
sliding it outward.
Screw
