PRODUCT OVERVIEW
2.2 Printer Rear View
1. Y-Axis
2. Extruder Assembly
3. Rear Thumbwheels
4. Z-Axis
5. Plug Socket
6. Power Switch
1. MicroSD Card Slot
2. Restart Button
3. LCD Display Screen
4. Dial button
5. USB Port
1
3
2
4
65
2.3 Control Panel
1
2
5
4
3
