WMF 5000S+ - Appendix: Technical data

101
User Manual WMF5000 S +
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 325mm
Height 716mm (with lockablebean hopper)
Depth 590mm
Coffee bean hopper approx. 1,100g per load
(1
Coffee bean hopper in the center approx. 700g
(1
Powder hopper (optional) approx. 2,000g
(2
Weight empty approx. 37kg (depending on the model)
Water supply 3/8inch hose connector with mains tap, and dirt
filter with 0.08mm mesh size, on site.
(3
At least 0.2MPa (2bar) supply pressure at 2l/min
Maximum 0.6MPa (6bar).
Maximum inlet temperature 35°C.
The set of hoses provided with the new coffee
machine and/or the new water filter must be used.
Do not use the old set of hoses.
Water quality For drinking water with carbonate hardness from
5°dKH or higher, aWMFwater filter must be fitted.
Water drain tube (optional) Hose aminimum of DN 19, minimum downward
slope of 2cm/m
Use at elevation above sea
level
< 2,000m
We reserve the right to make technical modifications.
(1
The capacity depends on the size of the coffee beans.
(2
Only with optional powder hopper. The capacity depends on the powder used.
(3
These specifications (IEC60335–2-75) for the water connection to the coffee
machine apply in EU member states. It may be necessary to also observe
additional country-specific regulations. Outside the EU acceptance of the
standards quoted is to be checked by the legal entity or natural person who
wishes to use the coffee machine.
