WMF 5000S+ - Page 102

102
User Manual WMF5000 S +
Appendix: Technical data
Nominal power rating 2.75–3.25kW 9kW
Power supply 220–240V, 50/60Hz,
(1/N/PE)
380–415V, 50/60Hz,
(3/N/PE)
Illumination LED
Degree of protection IP X0
Protection class class 1
Calibration pressure Boiler 0.5MPa (5bar)
Steam boiler 1.6MPa (16bar)
Continuous sound pressure level
(Lpa)
< 70dB(A)
(4
Ambient temperature +5°C to maximum +35°C
(empty the water system in case of frost).
Maximum humidity 80 % relative humidity without condensation.
Do not use device outdoors.
Installation surface/water spray The device must be placed and leveled on
ahorizontal, sturdy, water-resistant, and
heatproof base.
The device must not be cleaned using awater
jet. The device must be installed where it is
protected against water spray. The device must
not be located on asurface that is sprayed or
cleaned with awater hose, steam jets, steam
cleaner, or similar devices.
We reserve the right to make technical modifications.
(4
A-evaluated sound pressure level Lpa (slow) and Lpa (impulses) at operating
personnel workplace is under 70dB(A) in any working mode.
