WMF 5000S+ - Page 103

103
User Manual WMF5000 S +
Appendix: Technical data
Installation clearances For operating, service, and safety reasons the
machine should be installed with aclearance
from the building or non-WMFcomponents of
not less than 50mm at the sides and 50mm at
the back.
A minimum working space of 800mm in front
the coffee machine and overhead clearance of
at least 200mm above the product hoppers are
recommended. Aclear height of 1,100mm from
the top of the supporting surface should be
ensured. The height of the installation surface
above the floor is at least 850mm. If the coffee
machine connections are to be run downwards
through the counter, please make space for the
lines, which can reduce the usable space below
the machine.
Installation dimensions of the
water filter
See the User Manual for the water filter.
We reserve the right to make technical modifications.
