373064298_201507
25. Power supply to the indoor module
Opening the control unit cover
Cable entry/
fuse replacement
Fuse F1
Cable entry
AWO communication PCB
Opening / unhooking indoor
module casing
Terminal strip X1
HCM-3 control PCB
Contactor for electric heating
