Wolf BWL-1 S - Overview Of System Configurations

653064298_201507
31.3.3Overviewofsystemcongurations
Systemcong. Description
01 Cylinder in series, one heating circuit, DHW heating, active cooling possible (in conjunction
with an add. 3-way diverter valve for cooling)
02 Cylinder in series, DHW heating, can be extended with mixer circuits, can be extended with
solar circuit
05 Cylinder in series via 3-way valve, one heating circuit, DHW heating, can be extended with
solar circuit, active cooling possible
11 Separating cylinder, one heating circuit, DHW heating
12 WoodgasicationboilerBVG/TOB,straticationcylinderBSP-W/BSP-W-SL/BSH,DHW
heating, can be extended with mixer circuits, can be extended with solar circuit
14 WoodgasicationboilerBVG/TOB,straticationcylinderBSP-W/BSP-W-SL/BSH,DHW
heating, can be extended with mixer circuits, can be extended with solar circuit, active cooling
possible
15 Separating cylinder, one heating circuit, DHW heating, can be extended with mixer circuits,
can be extended with solar circuit, active cooling possible
33 Separating cylinder, CGB-2, one heating circuit downstream of low loss header, DHW heating,
can be extended with mixer circuits, can be extended with solar circuit
34 TOB,straticationcylinder,BSH/BSP-W/BSP-W-SL,DHWheating,canbeextendedwith
mixer circuits, can be extended with solar circuit
51 0 - 10 V activation for external demand (e.g. by building management system, BMS), central
heating, DHW heating, active cooling possible
52 On-off activation for external demand (e.g. by building management system, BMS), central
heating, DHW heating
The entire system must be restarted (power off / power on) each time a change is made to the
conguration.
Note:
Hydraulic diagrams and electrical details can be found on the Wolf homepage and in the "Hydraulic System
Solutions" technical guide.
ThefollowingsystemcongurationscanbeperformedforoperatingtheBWL-1SandBWL-1SB.
Contractor
parameter
Meaning Setting range Factory setting Individual setting
System
WP001 Systemconguration 01, 02, 05, 11, 12, 14,
15, 33, 34, 51, 52
01
31. Contractor level
