Wolf BWL-1 S - Split Heating Centre with CEW-2-200

333064298_201507
21. Split heating centre with CEW-2-200
The CEW-2-200 can be installed in combination with the BWL-1S-07/10/14 or
BWL-1SB-07/10/14 as a stacked heating centre.
Split heating centre
with CEW-2-200
Minimum clearances
for split heating centre
with CEW-2-200
Split heating centre with CEW-2-200
Height of indoor module A mm 790
Height of CEW-2-200 B mm 1290
Overall height C mm 2080
Overall height with 25 l expansion vessel (DEV)
(accessory - on back of indoor unit)
D mm 2160
Width E mm 650
Depth mm 685
≥2100(2200*)
≥800
≥300
≥500
Service clearances
OverallheightwithDEV*
Further information can be found in the instructions for the CEW-2-200 and the
CEW-2-200 connection set.
