Connectiontoamoisture-resistantbalancedue
chimneytypeC43x
Straight balanced ues must be no longer than 3 m when
connecting the system to a balanced ue chimney. In addition
to the boiler connection tee, up to two 90° diverters may be
installed.
The balanced ue chimney must be CE-designated.
Connectiontoamoisture-resistantuetypeB23foropen
ueoperation
The straight, horizontal ue must be no longer than 3 m. In
addition to the boiler connection tee, up to two 90° diverters
may be installed in the horizontal ue.
The ue gas chimney must be CE-designated.
The straight, horizontal ue must be no longer than 3 m.
For horizontal air supply pipes, a maximum length of 3 m is
recommended. Observe special requirements for ues that are
not surrounded by combustion air in accordance with locally
applicable combustion regulations.
Connectionto a moisture-resistantuetype C53, C83x
forbalancedueoperation
Connection to a combustion air and ue system type
C63x that is not tested together with the oil combustion
equipment
Original Wolf components are designed for long-term use and
are matched for use with Wolf oil condensing boilers. When
using CE-designated third party equipment, the installer is
responsible for the correct sizing and perfect function of such
systems. Faults, material losses and injuries resulting from
incorrect pipe lengths, excessive pressure drop, premature
wear with escaping ue gas and condensate or incorrect
function, e.g. through components working themselves loose,
are excluded from our warranty if non-approved third party
equipment is used.
Straight balanced ues must be no longer than 3 m, when
connectingthesystemtoacombustionairsupplyanda
separateue.
In addition to the boiler connection tee, up to two 90° diverters
may be installed.
The chimney must be free from contamination if the combustion
air is drawn from the chimney.
Connectiontoamoisture-resistantuegaschimneyora
uesystemtypeB33foropenueoperation
Straight balanced ues must be no longer than 3 m when
connecting the system to a ue gas chimney. In addition to the
boiler connection tee, up to two 90° diverters may be installed.
The ue gas chimney must be CE-designated.
If necessary, the ue outlet should be obtained from the
chimney manufacturer.
The air apertures to the boiler room must be completely free
from obstruction.
31. Design information
Connectiontomoisture-insensitiveuegaslineondoubleormultiple-uechimneys(shaft)
The requirements according to DIN 18160-1 supplementary sheet 3 apply.
The responsible local chimney sweeper is to be informed before the installation.
Room air-dependent operating mode only
Fully stainless steel
shaft cover from the Wolf
scope of supply
Chimney
T400
Room air-dependent and room air-independent operating modes
1000
Shaft cover from
the Wolf scope
of supply
Chimney
T400
System made of polypropylene,
up to 120 °C, CE-approved
System made of polypropylene,
up to 120 °C, CE-approved
