Troubleshooting Guide
5-10
Figure 5-9. Error Codes and Displayed Messages
Internal Components
ERROR CODE CHART (cont.)
Priority Displayed Phrase Service Instruction
2 Outer Bake relay shorted
Check connections, replace Relay Module of the oven
indicated
2 Broil relay shorted
2 Left Convect relay shorted
2 Right Convect relay shorted
2 MDL relay shorted
3 Left Convect Fan triac shorted
3 Right Convect Fan triac shorted
3 Cooling Fan triac shorted
3 Oven Light relay shorted
2 DLB1 shorted
2 DLB2 shorted
3 Aux DLB shorted
3 Inner Bake relay open
3 Outer Bake relay open
3 Broil relay open
3 Left Convect relay open
3 Right Convect relay open
3 MDL relay open
3 Left Convect Fan triac open
3 Right Convect Fan triac open
2 Cooling Fan triac open
3 Oven Light relay open
2 DLB1 relay or TCO open
2 DLB2 relay open
2 Aux DLB open
2 RTD Circuitry error
3 RM EE checksum error
3 HIV SPI com err detected by RM control
3 HIV SPI com err detected by HV-micro
3 HIV micro feedback error
1 RM LOV fuse error
3 RM HIV fuse error
2 HSWD active, should be inactive
2 HSWD inactive, should be active
3 RM Ambient Thermistor open error
3 RM Ambient Thermistor shorted error
3 RM Line Voltage A/D error
2 MDL circuitry error
2 RM FMEA circuitry error
1 Keypad circuit error
Check keypad & connections
1 Keypad comm error detected by the UIM
1 Keypad comm error detected by the Keypad
1 Keypad FMEA error
1 Keypad EE CRC error
3 Keypad mains sync error
To Next Page
