Element Wire # Plug Terminal
Ohm
Test
Wire # Plug Terminal
Upper Right
Convection or
Single Oven
11-E10 P13 3 9-RCvtE9 P12 6
Upper Left
Convection or
Single Oven
11-E10 P13 3 7-LCvtE8 P12 1
Upper Broil or
Single Oven
5-E5 P11 4 4-BroilE4 P11 1
Upper Outer
Bake or
Single Oven
5-E5 P11 4 2-ObakeE3 P10 4
Upper Inner
Bake or
Single Oven
5-E5 P11 4 1-IbakeE2 P10 1
Lower Broil 16-E25 P15 4 15-BroilE24 P15 1
Lower Outer
Bake
16-E25 P15 4 13-ObakeE23 P14 4
Lower Inner
Bake
16-E25 P15 4 12-IbakeE22 P14 1
E-SERIES Element Ohm Testing
