PAGE 35
Priority Displayed Phrase Service Instruction
1 Keypad circuit error
Check keypad & connections
1
Keypad comm error detected by
the UIM
1
Keypad comm error detected by
the Keypad
1 Keypad FMEA error
1 Keypad EE CRC error
3 Keypad mains sync error
3 UIM EE checksum error
Replace UIM Module
1 UIM configuration data CRC error
1 UIM fuse error
3 UIM ambient thermistor open error
3
UIM ambient thermistor shorted
error
1 LCD module error
2
Communications error detected by
the UIM
Check com harness, replace
Relay Module
2
Communications error detected by
the RM
Check com harness, replace UIM
Module
2 Overtemp error - door unlocked
Check door motor assy & wiring,
replace Relay Module
2 Overtemp error - door locked Replace Relay Module
2 RM Ambient overtemp error
Check air flow, verify cooling fan
operational, replace relay module
2 UIM Ambient overtemp error
Check air flow, verify cooling fan
operational, replace UIM.
3 Self-clean rate-of rise error
Check ovenfor leaks, insulation
problems. Run diagnostics, look
for open ouptuts or loads
E-SERIES Error Code Chart (cont.)
