PAGE 37
Valid Keys
1. BEEPER TEST
2. BROIL ELEMENT TEST
3. LEFT CONVECT ELEMENT TEST
4. RIGHT CONVECT ELEMENT TEST
5. INNER BAKE ELEMENT TEST
6. OUTER BAKE ELEMENT TEST
7. COOLING FAN TEST
8. MOTORIZED DOOR LOCK TEST
9. LEFT CONVECT FAN TEST
10. RIGHT CONVECT FAN TEST
11. LIGHTS TEST
UPR/LWR
OVEN LIGHT
9
8
7
6
CONV. BAKE
BAKE
CONV. BROIL
CONVECTION
BROIL
TIMED COOK
Switch to opposite cavity as currently displayed
Double Oven Goes to
initial test of Opposite
Cavity. Single Oven
goes to initial test of
cavity
"ENTER"
"ENTER"
"ENTER"
"ENTER"
"ENTER"
"ENTER"
"ENTER"
"ENTER"
"ENTER"
"ENTER"
Definitions/Clarifications:
Toggle: Means to switch
between the test or load
on or off.
Initial Manual Test Entry
LOCK Return to initial Service Menu
MANUAL
TEST
E-SERIES Diagnostic/Showroom Manual Menu Flow Chart
NOTE: See
Technical
Service
Manual
807792,
Section 5 to
view full
size.
