3
Layout
1. Saw table
2. Saw blade guard
3. Extraction hose
4. Splitter
5. Saw blade
6. Table insert
7. Parallel stop
8. Hand wheel
9. Adjusting and locking grip
10. Base frame
11. ON/OFF switch
12. Guide rail
13. Cross stop
14. Width extension table
15. Length extension table
16. Extractor adapter
17. Push stick
18. Legs
19. Longitudinal and cross struts
20. Center struts
21. Rubber feet
22. Stability bar
23. Table supports
24. Screw with wing nut
25. Oval hole in splitter
26. Countersunk head screws
27. Fixing screw
28. Eccentric lever
29. Groove
30. Knurled screw
31. Laser
32. Laser switch
33. Screws for battery compartment
34. Battery compartment cover
WZTS_1700_AUS_SPK7.indb 16 21.05.12 15:54
