6.6 Cross stop (Fig. 31-32)
• Slide the cross stop (13) into the groove (29) of the table.
• Slacken the knurled screw (30).
• Turn the cross stop (13) until the arrow points to the angle required.
• Retighten the knurled screw (30).
• When cutting large parts of workpieces you can use the stop rail (e)
from the parallel stop (7) to extend the length of the cross stop (13)
(Fig. 32)
• To extend the cross stop (13) with the stop rail (e), the stop rail (e), the
chain bar (h) and the wing nuts (f) must be removed together with
the washers of the parallel stop (7). Now mount the stop rail as shown
in Figure 32, using the lock bolts (n).
m Important!
• Do not push the stop rail (e) too far toward the blade.
• The distance between the stop rail (e) and the blade (5) should be
approx. 2 cm.
6.7 Adjusting the scale on the cross stop (Fig. 33)
• Place a 90° stop angle against the saw blade (5).
• Connect the cross stop (13) to the stop rail (e) of the parallel stop (7)
(refer to point 6.4).
• Undo the knurled screw (30) of the cross stop (13).
• Position the cross stop (13) so that the stop rail (e) is in a 90° angle to
the saw blade (5). Now precisely align the cross stop (13) to the saw
blade (5) using the 90° stop angle and retighten the knurled screw
(30).
• Check if the cross stop (13) is aligned at exactly 90°. If this is not the
case, continue as follows:
• Undo the two screws (o) holding the scale (p) to the cross stop (13)
until the scale can be set to the correct position.
• Retighten the screws (o).
