Adjustment of the page limitation
PRINCESS – Edition: 17.02.2005
11
OPERATING INSTRUCTIONS
2.6 Adjustment of the page limitation
If les than 100 CDs are installed it is useful to disable the
not needed pages. It will be done by two BCD switches at
the front side of the book.
For easy handling you can use the table below to adjust
the two switches.
Nevertheless you will find here an example how to calcu-
late the BCD switch adjustment.
The switch BCD1 has a valency of 16, the other one,
BCD2 a valency of 1. The meaning of the characters is
according to the hexadecimal character set:
A = 10 B = 11 C = 12
D = 13 E = 14 F = 15.
If you want to adust a number of 60 CDs divide 60 by 16.
It equals 3,75. The number before the decimal point has to be adjusted at BCD1. Ignore the num-
bers after the decimal point. After this multiply the adjusted number 3 by 16. It equals 48. Subtract
this number from the given number 60. This equals 12. Adjust this number at BCD2 as „C“ (=12) ac-
cording to the hexadecimal character set.
Pages BCD1 BCD2 Pages BCD1 BCD2 Pages BCD1 BCD2 Pages BCD1 BCD2 Pages BCD1 BCD2
101261A5133764C10165
202271B5234774D10266
303281C5335784E10367
404291D5436794F10468
505301E5537805010569
606311F563881511066A
7073220573982521076B
8083321583A83531086C
9093422593B84541096D
10 0 A 35 2 3 60 3 C 85 5 5 110 6 E
11 0 B 36 2 4 61 3 D 86 5 6 111 6 F
12 0 C 37 2 5 62 3 E 87 5 7 112 7 0
13 0 D 38 2 6 63 3 F 88 5 8 113 7 1
14 0 E 39 2 7 64 4 0 89 5 9 114 7 2
15 0 F 40 2 8 65 4 1 90 5 A 115 7 3
16 1 0 41 2 9 66 4 2 91 5 B 116 7 4
17 1 1 42 2 A 67 4 3 92 5 C 117 7 5
18 1 2 43 2 B 68 4 4 93 5 D 118 7 6
19 1 3 44 2 C 69 4 5 94 5 E 119 7 7
20 1 4 45 2 D 70 4 6 95 5 F 120 7 8
21 1 5 46 2 E 71 4 7 96 6 0
22 1 6 47 2 F 72 4 8 97 6 1
2317 4830 7349 9862
24 1 8 49 3 1 74 4 A 99 6 3
25 1 9 50 3 2 75 4 B 100 6 4
4
4
0
0
1
1
2
2
3
3
7
7
B
B
F
F
A
A
E
E
6
6
5
5
D
D
9
9
8
8
C
C
4
0
1
2
3
7
B
F
A
E
6
5
D
9
8
C
4
0
1
2
3
7
B
F
A
E
6
5
D
9
8
C
BCD1
BCD2
