Wurlitzer PRINCESS - Free play programming; Color codes of coin input

Free play programming
PRINCESS – Edition: 17.02.2005
23
OPERATING INSTRUCTIONS
7.3 Free play programming
Set a jumper from 0 to F (free play) in the row GP
on the SCC unit and be sure that jumper GP+6 is
removed. Then press ‘LT’ button.
Now one track is selectable without coin insertion.
In between two to six plays are selectable by set-
ting an additionally jumper in the row ‘BS’ (Bonus
Step) from 0 to 2 or from 0 to 6.
Up to 47 tracks are pre-selectable by setting a jum-
per in this row ‘BS’ from 0 to 7.
7.4 Color codes of coin input
