Wurlitzer PRINCESS - The operating mode STEREO

Speaker connections
PRINCESS – Edition: 17.02.2005
46
FIELD SERVICE MANUAL
11.5.1 The operating mode STEREO
For normal operation the jukebox is set to the STEREO mode. Both amplifier switches, the mode
switch and the slide switch S1 on the power amplifier board are set to position STEREO.
Example1:
Two 8Ω speaker connected in parallel
per channel
Example 2:
2 times 4 Ω speaker connected in se-
ries and in parallel with one 8Ω spea-
ker
Low Level
BGM
Mic.-Kit
L
R
Line Out
L
R
Input Tape
L
R
Input CD
Amplifier F91
0039155
BGM Level
R
L
LR
Clipping
P10
Remote
P10
Remote
P4
1
2
4
1
2
4
Tone
off on
Treble
Bass
R
L
S1
S1
P12
Volume
Mode
Input
CD
Stereo
Tape
2-Kanal
R
mode switch
position
STEREO
2-channel / Stereo
slide switch S1
L
R
2K
+/- Volume
8
100W
+
_
8
100W
+
_
8
100W
+
_
8
100W
+
_
monitor
speaker
L.H.
terminal
R.H.
terminal
2-channel / Stereo
slide switch S1
L
R
2K
+/- Volume
8
100W
+
_
4
50W
4
50W
+
_
+
_
8
100W
+
_
4
50W
4
50W
+
_
+
_
monitor
speaker
L.H.
terminal
R.H.
terminal
2-channel / Stereo
slide switch S1
