For Your Safety
GB
Please read and comply with
these operating instructions prior
to initial operation of your
device. Keep these operating
instructions for later use or for a
subsequent owner.
▸ Prior to rst use always read the safety instruc-
tions!
— Failure to observe the operating instructions and
the safety instructions could result in damage to
the device and danger for the operator and other
persons.
Always wear your personnel protective
equipment.
▸ Use only genuine Würth accessories and
spare parts.
Signs and symbols
The signs and symbols in these instructions should
help you to use the instructions and the tool quickly
and safely.
Note
Provides information on the most eec-
tive or most practical use of the tool.
▸ Handling step
The dened sequence facilitates correct and safe
use of the device.
3 Result
The result of a sequence of operating steps is
described here.
[1] Item number
Item numbers are indicated in the text with
square brackets [].
Intended use
The tool is intended to be used for setting steel, alu-
minium and stainless steel M4 to M12 rivet nuts and
steel, aluminium and stainless steel M5 to M8 rivet
bolts using genuine Würth system parts.
Any other use is considered an improper use.
The user alone is responsible for damage
resulting from improper use.
Items supplied (Fig. V)
Pos. Description Art.
1
Manual riveting machine without
mandrel and sleeve
0948 900
11
Mouthpiece with M4 lock nut 0949 919
12
Mouthpiece with M5 lock nut 0949 920
13
Mouthpiece with M6 lock nut 0949 921
14
Mouthpiece with M8 lock nut 0949 922
15
Mouthpiece with M10 lock nut 0949 923
16
Mouthpiece with M12 lock nut 0949 924
2
M4 threaded mandrel 0949 904
3
M5 threaded mandrel 0949 905
4
M6 threaded mandrel 0949 906
5
M8 threaded mandrel 0949 908
6
M10 threaded mandrel 0949 910
7
M12 threaded mandrel 0949 912
8
M5 threaded sleeve 0949 915
9
M6 threaded sleeve 0949 916
10
M8 threaded sleeve 0949 918
Flawless performance can only be guaranteed with
original mandrel inserts.
