Xantrex C35 User Manual

Adjusting the C-Series Voltage Settings
975-0004-01-02 Rev D 27
Figure 2-14 Voltage Settings with R46 Resistor Clipped
CAUTION: Damage to Batteries
It is not recommended to allow an equalize charge to occur if the
R46 Resistor is clipped. Higher charging voltages may damage the
batteries. Make sure the EQ/LVR jumper is on the MANUAL
Setting.
12-Volt System Settings
24-Volt System Settings
17.0
15.0
1
6.0
BULK (CHG
)
15.2
15.4
15.6
15.8
16.2
16.4
16.6
16.8
FLOAT (CHG
)
16.5
14.5
1
5.5
14.7
14.9
15.1
15.3
15.7
15.9
16.1
16.3
48-Volt System Settings (C40 only)
34.0
30.0
3
2.0
BULK (CHG
)
30.4
30.8
31.2
31.6
32.4
32.8
33.2
33.6
FLOAT (CHG
)
33.0
29.0
3
1.0
29.4
29.8
30.2
30.6
31.4
31.8
32.2
32.6
68.0
60.0
6
4.0
BULK (CHG
)
60.8
61.6
62.4
63.2
64.8
65.6
66.4
67.2
FLOAT (CHG
)
66.0
58.0
6
2.0
58.8
59.6
60.4
61.2
62.8
63.6
64.4
65.2
