Xantrex C35 User Manual

Diversion Control Troubleshooting
975-0004-01-02 Rev D 67
Diversion load operates
while a generator (fuel
powered) is running.
Bulk Voltage setting on
diversion controller is
set too close to other
charger settings.
A. Bulk voltage on
controller needs to be set
higher than other charging
sources or use a
switch/relay to disable the
diversion load while using
a generator.
Diversion load operates
immediately at full
power when load
breaker is turned on.
Mode jumper is set for
“Load Control” instead
of “Charge Control”.
Change jumper setting.
Table 4-2 Diversion Control Problems
