Xantrex Freedom SW Series User Manual

97-0019-01-01 99
Troubleshooting
F85 PowerBoard
Over
Temperature
Automatic Same as F57. Same as F57.
F86 Dead Battery
Detected
Automatic When battery voltage
is below the allowable
charging voltage.
Recharge the battery with an external
charging device.
If the error persists, then the battery
may be defective. Replace the battery.
F88 MPPT Ground
Fault
Automatic In a Xanbus network,
an MPPT has detected
a ground fault (MPPT
generated code F56).
Check the MPPT and correct the
ground fault.
Table 3 Detected Fault Messages
Fault
Number Message Fault Type Cause Solution
FSW Owners Guide.book Page 99 Tuesday, August 7, 2018 9:03 AM

Xantrex Freedom SW Series Specifications

General

Output Voltage	120 VAC
Output Frequency	60 Hz
AC Transfer Switch	Yes
Battery Charger	Yes
Input Voltage	12V, 24V, 48V DC
Protections	Over temperature, overload, short circuit
