Problem Solving
7-32 Xerox 4112/4127 EPS
User Guide
e. Lift up lever 2c and remove the jammed paper.
5. Lift up the lever 2c as necessary, shift the lever 2d, and then remove the jammed paper.
6. Turn the knob 2f as necessary and then remove the jammed paper.
WARNING
Never touch the six Fuser Stripper Fingers which are visible when you lift up the lever 2c. Fuser
Stripper Fingers are HOT can lead to burns if touched.
WARNING
Never touch a labeled area (found on the fuser unit or nearby) indicating “High Temperature” and
“Caution.” Contact can lead to burns.
To Next Page
