Problem Solving
Xerox 4112/4127 EPS 7-33
User Guide
7. Shift lever 3b on the right of the fuser unit as necessary and then remove the jammed
paper.
Tip
If the jammed paper remains inside and it is difficult to remove, pull out the duplex module
after returning the transfer module to the original position. Then try again.
8. Insert the transfer module completely and turn the green lever 2 to the left.
Note
If the lever cannot be turned, pull the transfer module to the middle and insert it again.
9. Close the front cover completely. The machine will not operate if the front cover is open
even slightly.
To Next Page
