Loading media in the Bypass tray
When using the Bypass tray (Tray 5):
• This tray is used primarily when using a small quantity and special media (such as
envelopes).
• Stock can be loaded either long or short edge feed (portrait or landscape).
• You must manually enter the paper size on the machine UI.
• If you use a non-standard paper size often, you can preset the paper size in the device.
The preset size then displays under Standard Sizes in the Tray 5 (Bypass) screen. For
information about setup, refer to the System Administration Guide.
• You can load up to 250 sheets of 20 lb/75 gsm paper.
• Do not load mixed-size paper into the Bypass tray (Tray 5).
• Do not load materials above the MAX line as indicated on the tray.
Loading paper in the Bypass tray (Tray 5)
1. Gently extend the Bypass tray (Tray 5) as necessary to accommodate the paper.
2. Hold the center of the paper guides and slide them to the desired paper size.
3. Select the appropriate paper stock for your print job.
4. Open the ream of paper with the seam side facing up.
5. Fan the sheets before loading them into the tray.
4-5
Xerox
®
770 Digital Color Press
User Guide
Paper and other media
