Xerox COLORQUBE 8870 User Manual

Troubleshooting
ColorQube 8570/8870 Color Printer
User Guide
165
To print the Troubleshooting Print Quality page in CentreWare IS:
1. Launch your Web browser and type your printer’s IP address into the browser Address field.
2. At the CentreWare IS page, click the Support button or tab.
3. In the navigation pane on the left, expand the Troubleshooting folder.
4. Click the Troubleshooting Pages link.
5. Select Troubleshooting Print Quality and then click the button below the list of pages.
See also:
Information Pages on page 23
Selecting a Print-Quality Mode
Print-quality modes available with the ColorQube 8570/8870 printer are driver dependent.
PostScript Driver
Set the print-quality mode for the PostScript driver in the driver settings on your computer, on the
printer control panel, or in CentreWare IS.
The print-quality modes for the PostScript driver are described in the following table. To preview each
mode, print the Print Mode Demonstration pages. For details, see Sample Pages on page 25.
Print-Quality Mode Type of Print Job
Fast Color Fastest full-color mode, useful for many images and previewing
your work. Rapidly produces review documents; useful for rush
jobs. Not recommended for documents containing small text, fine
detail, or large areas of bright, solid fill.
Automatic Available from the printer driver only. When selected, the
print-quality mode used for the print job is Photo when the paper
type is Glossy, and Enhanced for all other paper types.
Standard General-purpose mode for full-color printing. Produces crisp, bright
prints at high speed. Recommended for vibrant, saturated color
prints.
Enhanced (default) Best mode for business presentations. Produces superior text
resolution and very smooth light colors. This mode takes longer to
process and print than Standard or Fast Color.
Photo Highest-quality mode for color prints. Provides the best detail and
smoothness for photographic images. Produces highest-quality
color prints, with the best text resolution and smoothest light
colors. This mode takes longer to process and print than the other
modes.

Xerox COLORQUBE 8870 Specifications

General

Wi-Fi	-
Network ready	Yes
Security algorithms	HTTPS, SSL/TLS
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Maximum duty cycle	120000 pages per month
Recommended duty cycle	15000 pages per month
Page description languages	PCL 5c, PostScript 3
Maximum internal memory	2048 MB
Sound power level (standby)	24 dB
Display	LCD
Certification	EMC Directive 2004/108/EC, FCC Part 15, Class A, Low Voltage Directive 2006/95/EC, RoHS Directive 2002/95/EC
Total input capacity	625 sheets
Total output capacity	350 sheets
Maximum input capacity	2200 sheets
Envelopes sizes	C5, DL
Maximum print size	216 x 356 mm
Media weight (tray 1)	60 - 220
Paper tray media types	Bond paper, Card stock, Coated paper, Envelopes, Glossy paper, Labels, Photo paper, Plain paper, Recycled paper, Transparencies
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Business cards, Envelopes, Greeting cards, Heavyweight paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	107 W
Power consumption (printing)	252 W
Power consumption (PowerSave)	47 W
Package weight	35811 g
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Depth (imperial)	20.5 \
Width (imperial)	16 \
Height (imperial)	14.5 \
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.1x
Minimum storage drive space	160 GB
Compatible operating systems	HP UX 11, HP UX 11i, Linux, Mac OS 10.5+, Solaris 10, Solaris 9, Windows 2003 Server, Windows 2008 Server, Windows 7, Windows Vista, Windows XP, Windows XP Pro

Weight and Dimensions

Depth	521 mm
Width	406 mm
Height	368 mm
Dimensions (WxDxH)	406 x 521 x 368 mm
