1. Setting up the DocuColor 2006 Installing the Scanner Stand
1-42 Xerox DocuColor 2006
8. Turn the Upper Assembly over, and slide it into the legs of the Lower
Assembly until it stops.
301140a
9. Attach the two assemblies together using eight Allen Screws and the
Allen Wrench.
301139a
10. Install the two Bumpers into the rear slots of the bottom plate.
301141a
