Installing the Document Feeder 1. Setting up the DocuColor 2006
Xerox DocuColor 2006 1-51
6. To install the Document Feeder perform the following steps:
WARNING
The Document Feeder weighs 24 pounds (11kg). Use extreme care when
handling the feeder.
a. Remove the protective packing from the front edge of the
Document Feeder.
0
3301227A
-W O L
b. From the back of the Scanner, align the holes in the Document
Feeder hinges to the alignment posts on the Scanner.
0
301229A
-
WOL
To Next Page
