58 I-Class
4.1.7 Diagnostics
HEX DUMP MODE Most commonly used for troubleshooting.
Prints data and instructions received from
the host rather than interpreting them as
label formats; see Section 6.2.
ENABLE
Prints raw ASCII data received from the
host rather than executing the commands.
²DISABLE
Executes and prints label formats (normal
operating mode).
OPTIONS TESTING Tests currently installed options
TEST PRESENT SENSOR
Performs a functional test of the Present
Sensor circuitry.
TEST CUTTER
Performs a functional test of the optional
cutter mechanism and circuitry.
PERFORM TEST
1 TIME
The cutter will cycle 1, 10 or 100 times
(selectable). The results of each attempt
will be displayed.
MONITOR GPIO INPUT
TEST GPIO OUTPUT
TEST SCANNER
Performs a functional test of the Scanner.
SCAN TEST
Enters “read once mode.” A bar code is
read and the decoded results are displayed.
ALIGNMENT TEST
Enters “constant read mode.” Bar codes
are read; decoded results are displayed;
and, a read-count is incremented.
PRINT TEST RATE (min)
²000 (0-120)
The number of minutes to delay between
the printing of batches of labels in Quick
Test Mode.
