Xerox I Class User Manual

82 I-Class
5.3.2 Cleaning the Platen Roller
A platen roller contaminated with grit, label adhesive, or ink can cause a decline
in print quality and, in extreme cases, cause labels to stick and wrap around the
roller. To clean the platen roller:
Œ Turn ‘Off’ and unplug the printer.
• Open the access cover. Unlock the Printhead Latch and raise the Printhead
Assembly. Remove media and ribbon.
Ž Using a Cotton Swab dampened with isopropyl alcohol, clean the Platen
Roller; manually rotate the roller and repeat, cleaning the entire surface.
Allow the Platen Roller to dry.
• Replace ribbon and media.
• Lower the Printhead Assembly and rotate the Printhead Latch completely
back, to the locked position.
‘ Close the access cover. Plug in and turn ‘On’ the printer. Feed several labels
to normalize tracking.
CAUTION
NEVER use a sharp object to clean the Platen Roller.
