172 7 Maintenance
Feed Rolls Inside the Printer
1. If paper is loaded in Tray 1 (Bypass tray),
remove the paper and close Tray 1 (Bypass
tray) cover.
Important
• When closing Tray 1 (Bypass tray) cover, be careful
not to get your fingers caught between (the left and
right edge of) the cover and the printer.
2. Pull the front cover release levers ("A") on
both sides of the printer towards you and
open the front cover.
3. Identify the location of the feed rolls.
4. While rotating the feed rolls, wipe the
rubber part with a soft, damp cloth
moistened with water.
5. Open the front cover.
To Next Page
