Xerox VersaLink B7025 User Manual

Troubleshooting
212 Xerox
®
VersaLink
®
B7025/B7030/B7035 Multifunction Printer
User Guide
Clearing Paper Jams at Doors A, B and C
To resolve the error that appears on the control panel, clear all paper from the paper path.
Clearing Jams at Door A
1. Lift the release lever, then open Door A.
WA
RNING: The area around the Fuser can be hot. Use caution to avoid injury.
C
AUTION: Do not touch the transfer roller. Touching the roller can reduce image
quality.
2. Remove the jammed paper.
3. If paper is jammed at the exit to the output tray, to remove it, carefully pull it straight out in the
direction shown.
Note: Toner can adhere to the transfer roller. This does not affect print quality.

Xerox VersaLink B7025 Specifications

General

Print Speed	Up to 25 ppm
Print Resolution	Up to 1200 x 1200 dpi
Copy Resolution	Up to 600 x 600 dpi
Scan Resolution	Up to 600 x 600 dpi
Control Panel	5-inch color touchscreen
Duplex Printing	Standard
Processor	1.05 GHz
Memory	2 GB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Fax Transmission Speed	3 seconds per page
Display	5-inch color touchscreen
Connectivity	Ethernet 10/100/1000 Base-T, High-speed USB 3.0
Functions	Print, Copy, Scan
Media Sizes Supported	A4, A5, A6, B5
Printer Type	Laser
Copy Speed	Up to 25 ppm
Mobile Printing	Apple AirPrint, Google Cloud Print, Xerox Print Service Plug-in for Android
