Removing the Wireless Network Adapter
To remove the Wireless Network Adapter:
1. Power off the printer:
a. At the printer control panel, press the PPoowweerr//WWaakkee button, then touch PPoowweerr OOffff.
b. Open the front door, then press the power switch to the Off position.
CCaauuttiioonn:: Do not unplug the power cord while the printer powers down.
2. To release the Wireless Network Adapter from the connection panel on the side of the printer, gently grasp the
adapter and push the release lever to the side. Carefully pull the adapter away from the printer.
CCaauuttiioonn:: Do not use force to pull on the Wireless Network Adapter. If the latch is released properly, the
adapter pulls out easily. Pulling on the adapter can damage it.
46
Xerox
®
VersaLink
®
C71XX Series Color Multifunction Printer User Guide
Getting Started
