Combination of Output Functions and Destinations
Table Legend: O: Can be combined X: Cannot be combined
Function/ Combination of Functions SquareFold Functions
Output Destination
Booklet Trimmer
Square Fold
Booklet Tray Trimmer Booklet Tray
Offset X X
X
X X
Staple X X
X
X X
Punch X X
X
X X
Interposer O O
O
O O
Booklet - O
O*1
O O
Z-Fold X X
X
X X
Letter Fold X X
X
X X
Bi-Fold - O
O*1
O O
Offset X X
X
X X
Staple + Z-Fold X X
X
X X
Staple + Interposer X X
X
X X
Punch + Z-Fold X X
X
X X
Z-Fold + Interposer X X
X
X X
Staple + Puncher + Z-Fold X X
X
X X
Staple + Punch + Z-Fold + Interposer X X
X
X X
*1: Square-folding/trimming of non-stapled sets and square-folding of 4 or less sheets in a set are outside the specification and cannot be assured. Jams may
occur frequently or wrinkles may occur on the square-folded side of paper.
SquareFold Trimmer Skew Specification
Booklet + trimming Measure both sides of the bottom sheet when the booklet is output.
Staple: |L5-L6| ≤ 2 mm (Achievement rate: 95%)
Bi-Fold/Non-staple: |L5-L6| ≤ 3 mm (Achievement rate: 95%)
Booklet + trimming + square-folding Measure both sides of the bottom sheet when the booklet is output.
Staple: |L7-L8| ≤ 2.5 mm (Achievement rate: 95%)
Performance is not guaranteed at Bi-Fold/Non-staple.
Standard Finisher Plus
The Standard Finisher Plus provides the same functions as the Standard Finisher, although Stacker Tray capacity is reduced from 3,000 sheets to a maximum of
2,000 sheets. The Standard Finisher Plus adds a Finishing Transport module which enables connection to available third-party finishing solutions.
NOTE: A Standard Finisher cannot be upgraded to a Standard Finisher Plus. Finishing solutions that can be connected to the Standard Finisher Plus include:
Plockmatic Pro 35/50 Booklet Maker
GBC E-Bind.
Specifications and expectations for these devices are available in a Solutions Planning Guide which is available from your Xerox sales representative or analyst.
Standard Finisher Plus
Specifications
For information related to the Standard Finisher Plus, refer to Module Dimensions for Optional Devices.
Top Tray
NOTE: These specifications are the same as the Standard Finisher.
Standard Finisher Plus Top Tray Capacity by weight and paper finish
Paper type and weight Paper Size
Post Card
182x257 mm
A4
/
8.5 x 11 in
B4
/
8.5 x 14 in
A3
/
11 x 17 in
12 x 18 in* SRA3*
13 x 19.2 in*
Uncoated 52-80 gsm H=67mm
(2.64 in)
500
500
500
500 500
500
80-350 gsm H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
Coated 106-350 gsm H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
H=67mm
(2.64 in)
To Next Page
