Xerox WorkCentre 3655 - PL 15.1 Registration (1;3)

5/2014
5-20
WorkCentre 3655 Multifunction Printer
PL 15.1
Initial Issue - Xerox Internal Use Only
Parts Lists
PL 15.1 Registration (1/3)
Item Part Description
1
604K85750 Kit SW Assy I/L Rear
2 – Chute DUP Lower
3 – Spring WC IL
4 – (SCC) Harness Assy Interlink
5 – Spring Interlock
6 059K79334 (SCC) Transport Assy-Regi FDR
(PL 15.2)
7 – Lock Tray
8 – Plate Earth REGI OUT ZA
9 – Holder-Connector Rear Fan
10 – --
11 803E13351 Stopper CST ZA S3
1 { 2-4
