Xerox WorkCentre 3655 - PL 15.3 Registration (3;3)

5/2014
5-22
WorkCentre 3655 Multifunction Printer
PL 15.3
Initial Issue - Xerox Internal Use Only
Parts Lists
PL 15.3 Registration (3/3)
Item Part Description
1
– Bearing Nudger
2 – Feeder Assy
3 – Gear Feed
4 – Clutch One Way Feed
5 604K11192 Roll Assy Feed
6 – Shaft Assy Feed
7 – Plate Nudger
8 – Gear Idler Nudger
9 – Gear Nudger TI
10 – Shaft Nudger ZA
11 – Bearing Nudger D
