Xerox WorkCentre 3655 - Initial Issue - Xerox Internal Use Only Parts Lists

5/2014
5-25
WorkCentre 3655 Multifunction Printer
PL 18.2
Parts Lists
Initial Issue - Xerox Internal Use Only
PL 18.2 Electrical (2/4)
Item Part Description
1
– CVR MCU
2 960K74850 (SCC) MCU Board
3 – Bracket MCU
4 – Housing MCU
5 105K30954 (SCC) HVPS
6 – Stapler Assy (p/o item 99)
7 – Stapler Cartridge (p/o item 99)
8 – Housing Stapler
9 105K31920 (SCC) PWBA Stapler LVPS 220v
– 105K31930 (SCC) PWBA Stapler LVPS 110v
10 – Plate Sub LVPS
99 604K90550 Kit Stapler Assy
99 { 6, 7
