IP Sec
Xerox WorkCentre 4260 Series System Administration Guide 147
• 2001:DB8:1234:215:215:99FF:FE04:D345 / 128 is used to reference a complete
address.
• 2001:DB8:1234:215:215:99FF:FE04:D345 / 64 is used to reference prefix
address consisted of leftmost 64 bits only.
• 2001:DB8:1234:215:215:99FF:: / 80 is used to reference prefix address consisted
of leftmost 80 bits only.
14. Click on the [Apply] button to accept changes.
15. If prompted, enter the Administrator’s User ID [admin] and Password [1111], and
click on [Login].
16. Click on [OK].
IP Sec
IP Sec (IP Security) is comprised of the IP Authentication Header and IP Encapsulating
Security Payload protocols, that secure IP communications at the network layer of the
protocol stack, using both authentication and data encryption techniques. The ability to
send IP Sec encrypted data to the printer is provided by the use of a public cryptographic
key, following a network negotiating session between the initiator (client workstation) and
the responder (printer or server). To send encrypted data to the printer, the workstation and
the printer have to establish a Security Association with each other by verifying a matching
password (shared secret) to each other. If this authentication is successful, a session public
key will be used to send IP Sec encrypted data over the TCP/IP network to the printer.
Providing additional security in the negotiating process, SSL (Secure Sockets Layer
protocols) are used to assure the identities of the communicating parties with digital
signatures (individualized checksums verifying data integrity), precluding password
guessing by network sniffers.
Enable IP Sec
This procedure requires that you have a Shared Secret available.
IP Sec cannot be enabled until SSL (Secure Sockets Layer) is enabled on the machine.
1. At your Workstation, open your Web browser and enter the TCP/IP Address of the
machine in the Address bar.
2. Press [Enter].
3. Click on the [Properties] tab.
4. Click on the [Security] link.
5. Select the [IP Sec] in the directory tree.
6. Enable the Protocol by placing a checkmark in the [Enabled] box.
7. Enter the a password in the [Shared Secret] and [Verify Shared Secret] boxes.
8. Checkmark [Select to save new Shared Secret] box.
9. Click on the [Apply] to save settings.
