Customer Support Page 18
PostScript Feature List
Feature Description
Copies
The number of copies to produce, either of each page individually or of the document
as a whole, depending on the value of the Collation parameter.
Collation
A flag specifying how the output is to be organized when multiple copies are requested
for a multiple-page document.
Duplex Delivers two-sided output.
Tumble Deliver two-sided output. Use combined with Duplex.
Media Class Paper class (ex. normal, thick, recycled)
Media Color Use this command to indicate the color of the media used to print.
Media Direction
This command specifies the edge of the input medium that will enter the imager first
and across which data will be imaged. Values reflect positions relative to a canonical
page in portrait orientation (width smaller than height).
Media Selection Specify if you apply the strict setpagedevice rule to media selection.
Media Size This command specifies the size of media on which to print.
Media Source This command specifies the tray to supply the job’s media.
Media Source from Bypass tray This command indicates whether the input medium is to be fed from bypass tray.
Media Weight Media weight. Unit: (g/ ) gram per square-meter
Output Location Indicates the output bin where the print job is sent.
Image Enhancement Specify whether you apply edge-smoothing to output after rendering
Toner Save Use this command to control toner consumption when printing.
Halftone Screen Selection This command specifies the screen type.
Offset
This feature provides a physical offset of hard copy that distinguishes between sets or
stacks within a job.
Booklet This command enables you to print documents as small booklets.
Punch
This command indicates hole punches for a print job on a device with hole punch
capability.
Stapling This command indicates use and location of staple(s).
Print Mode This command sets the resolution and the color depth value.
Process Color Model Select process color model (DeviceGray, DeviceRGB, DeviceCMYK,,,)
RGB Correction Specify whether you apply RGB correction to the color conversion process
Gray Guaranteed
Specify whether to convert RGB black (R=G=B) to pure black for text and graphics
objects.
Gamma Correction Specify gamma value for RGB color conversion
CMYK Correction Specify whether you apply CMYK correction to the color conversion process
White Point Specify White Point of Client side
RGB Space Specify RGB Space for RGB correction
Brightness Specify brightness of output color
Separations Specify whether multiple color separations are generated for each page of output.
Separation Color Names Specify the process colorant name.
Separation Order Specify the order of process colorant name.
Use CIE Color Specify if you apply CIE-based color space through color conversion
Job Name
Job Type
(Secure Print / Proof Print / Box
Print)
Job Based Accounting
Auditron
Delay Print
Banner Sheet
These commands are the same as the ‘PCL/PJL Implementation’. Please refer the
PCL/PJL section.
