Examples
Basic PJL Template
This section illustrates a standard PJL template that is used to access general print features as well as WorkCentre
7120 specific features. This template lists each feature and the syntax, both PCL commands and PJL, required to use
these features.
Section 1 (Opening Command, Required for all files)
<ESC>%-12345X@PJL JOB MODE=PRINTER
Section 2 (PJL Set Commands)
@PJL SET RESOLUTION=600
@PJL SET COPIES=1
Section 3 (PCL Code used to invoke PCL Language)
@PJL ENTER LANGUAGE=PCL
Section 4 (PCL Data Stream or ASCII Document inserted here for Options such as selection
Different Fonts, Simplex, Duplex, etc.)
,,,,,,,,,,
Section 5 (Closing Command, Required at end of Document)
<ESC>%-12345X@PJL EOJ
Sample PJL Headers
Example 1 - Simple Print
Note:
This is a simple print job
header specifying the
output tray (MAINTRAY),
Quantity needed (1), and
Job Owner (Smith).
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL CO
MMENT Beginning PCL Job<CR><LF>
@PJL SET OUTBIN=MAINTRAY<CR><LF>
@PJL SET QTY=1<CR><LF>
@PJL SET RESOLUTION=600<CR><LF>
@PJL SET JOBATTR=”@JOAU=Smith” <CR><LF>
Note:
This is a Finishing Job
header asking for the
Stapling option that
specifies the job will be
sent to the Finisher Tray,
and stapled on the Top
Left hand corner or the
paper.
Example 2 - Finishing Options (Stapling)
<ESC>%-12345X@PJL JOB MODE=PRINTER<CR><LF>
@PJL SET OUTBIN=OUTBIN101<CR><LF>
@PJL SET FINISH=ON<CR><LF>
@PJL SET STAPLE=TOPLEFT<CR><LF>
