FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
20
Figure 5-7 Ports on the front panel
1
iBMC direct connect
management port
2
USB 3.0 port
3
VGA port
-
-
⚫
8 x 2.5" drive configuration
Figure 5-8 Ports on the front panel
1
iBMC direct connect
management port
2
USB 3.0 port
3
VGA port
-
-
⚫
10 x 2.5" drive configuration
Figure 5-9 Ports on the front panel
1
iBMC direct connect
management port
2
USB 3.0 port
