xFusion Digital Technologies FusionServer 1288H V6 User Manual

FusionServer 1288H V6 Server
Technical White Paper
5 Hardware Description
2022-06-25
21
Port Description
Table 5-2 Ports on the front panel
Port
Type
Quantity
Note
Description
VGA port
DB15
1
Used to connect a display
terminal, such as a monitor or
KVM.
iBMC direct
connect
management
port
USB Type-C
NOTE
The USB 2.0
protocol is
supported.
1
Used to connect to a local PC
through a USB Type-C cable to
monitor and manage the system.
NOTE
Only local PCs running Windows 10
are supported.
⚫
To log in to the iBMC from the
local PC, enter https://IP address
of the iBMC management network
port in the address box of the
browser on the local PC.
Used to connect to a USB device.
NOTICE
⚫
Before connecting an external
USB device, ensure that the USB
device functions properly.
Otherwise, it may adversely
impact the server.
⚫
For details about how to connect a
USB device to the iBMC
management port, see
FusionServer Rack Server iBMC
User Guide.
USB port
USB 3.0
2
Used to connect to a USB 3.0
device.
NOTICE
⚫
Before connecting an external
USB device, ensure that the USB
device functions properly.
Otherwise, it may adversely
impact the server.
⚫
The USB 3.0 port can be used to
supply power to low-power
peripherals. However, the USB
3.0 port must comply with the
USB specifications. To run
advanced peripherals, such as
external CD/DVD drives, an
external power supply is required.
Note: The number of ports varies depending on server configuration. This table lists the
maximum number of ports in different configurations.
