FusionServer 1288H V6 Server
Technical White Paper
A Appendix
2022-06-25
92
Sensor
Description
Component
N indicates the CPU
number. The value is 1 or 2.
CPUN MEM Temp
CPU memory module
temperature
Memory module
corresponding to CPU N
N indicates the CPU
number. The value is 1 or 2.
CPUN 12V
12 V voltage supplied by the
mainboard to the CPU
Mainboard
N indicates the CPU
number. The value is 1 or 2.
Riser 12V
12 V voltage supplied by the
mainboard to the riser card
Mainboard
Disk BP 12V
12 V voltage supplied by the
mainboard to the drive
backplane
Mainboard
CPUN DDR VDDQ
1.2 V memory module
voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN DDR VDDQ2
1.2 V memory module
voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN VCCIN
CPU VCCIN voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN VSA
CPU VSA voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN P1V8
CPU P1V8 voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN VCCIO
CPU VCCIO voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
CPUN VCCANA
CPU VCCANA voltage
Mainboard
N indicates the CPU
number. The value is 1 or 2.
FANN F Speed
Fan speed
Fan module N
N indicates the fan module
number. The value ranges
from 1 to 7.
FANN R Speed
Power
Server input power
Power supply unit (PSU)
