FusionServer 1288H V6 Server
Technical White Paper
A Appendix
2022-06-25
93
Sensor
Description
Component
PSN VIN
PSU N input voltage
PSU N
N indicates the PSU
number. The value is 1 or 2.
Disks Temp
Maximum drive temperature
Drive
RAID Temp
Temperature of the RAID
controller card
RAID controller card
PowerN
PSU input power
PSU N
N indicates the PSU
number. The value is 1 or 2.
PCH Status
PCH chip fault diagnosis
health status
Mainboard
CPUN UPI Link
CPU UPI link fault
diagnosis health status
Mainboard or CPU N
N indicates the CPU
number. The value is 1 or 2.
CPUN Prochot
CPU Prochot
CPUN
N indicates the CPU
number. The value is 1 or 2.
CPUN Status
CPU status
CPUN
N indicates the CPU
number. The value is 1 or 2.
CPUN Memory
Status of the memory
corresponding to the CPU
Memory module
corresponding to CPU N
N indicates the CPU
number. The value is 1 or 2.
FANN F Status
Fan fault status
Fan module N
N indicates the fan module
number. The value ranges
from 1 to 7.
FANN R Status
DIMMN
DIMM status
DIMM N
N indicates the DIMM slot
number.
RTC Battery
RTC battery status. An
alarm is generated when the
voltage is lower than 1 V.
RTC battery on the
mainboard
PCIE Status
PCIe status error
PCIe card
Power Button
Power button pressed
Mainboard and power
button
Watchdog2
Watchdog
Mainboard
Mngmnt Health
Management subsystem
Management modules
