Feature Descriptions
9 J25, J26 SMA GTP reference clock input Rosenberger 32K10K-400L5 3
10 U24
Jitter attenuated clock (back side of
board)
Silicon Labs SI5324-C-GM 16
11 U1 GTP transceivers Embedded within FPGA U1 30
12 P1 PCI Express® edge connector 4-lane card edge connector 28
13 P3 SFP/SFP+ connector Molex 74441-0010 20
14 U12 10/100/1000 tri-speed Ethernet PHY Marvell 88E1116RA0-NNC1C000 15
15 U2
GTP transceiver clock generator
125
MHz
ICS ICS84402IAGI-01LF 3
16 J17, U44
USB-to-UART bridge (back side of
board) and mini-B receptacle (front side
of board)
Silicon Labs CP2103GM 5
17 P2, U48 HDMI video connector and device
Molex 500254-1927, Analog Devices
ADV7511KSTZ-P
19, 18
18 J23 LCD character display connector 2 x 7 0.1 in male pin header 14
19 U52 I2C bus switch (back side of board) TI PCA9548ARGER 6
20 DS11–DS13 Ethernet PHY status LEDs, green Lumex SML-LX0603GW 15
21 DS2–DS5 User GPIO LEDs, green Lumex SML-LX0603GW 21
22 SW3 – SW7 User pushbuttons E-switch E-Switch TL3301EF100QG 21
23 SW2 GPIO DIP switch, 4-pole C&K SDA04H1SBD 21
24 SW10 User rotary switch Panasonic EVQ-WK4001 21
25 J33, J34 SMA user GPIO Rosenberger 32K10K-400L5 3
26 SW15 Power on/off slide switch C&K 1201M2S3AQE2 38
27 SW9
FPGA_PROG_B pushbutton switch
(active-Low)
E-Switch TL3301EF100QG 7
28 SW1 Configuration mode DIP switch, 3-pole C&K SDA03H1SBD 7
29 J30 FMC HPC connector Samtec ASP_134486_01 24–27
30
U8, U9,
U49,
U53-U60
Power management (voltage regulators
front side of board, controllers back side
of board)
TI UCD90120ARGC controllers in
conjunction with various regulators
39–50
31 J19 XADC header 2X10 0.1 inch male header 31
32
J44, J45, J46,
J47
MGT transmit, receive SMA pairs Rosenberger 32K10K-400L5 3
33 J2 PMBus connector Assmann AWHW10G-0202-T-R 38
34 J49 6 pin Molex mini-fit Jr. connector for 12V Molex 39-30-1060 38
Table 1-1: AC701 Board Component Descriptions (Cont’d)
Callout
Reference
Designator
Component Description Notes
Schematic
0381502
Page Number
Send Feedback
