Feature Descriptions
Power Management
[Figure 1-2, callout 30]
The AC701 board uses power regulators and PMBus compliant system controllers from
Texas Instruments to supply core and auxiliary voltages. The Texas Instruments Fusion
Digital Power GUI is used to monitor the voltage and current levels of the board power
modules.
The AC701 board power distribution diagram is shown in Figure 1-42.
J2 NC NA NA K1 NC NA NA
J3 NC NA NA K4 NC NA NA
J6 FMC1_HPC_HA03_P LVCMOS25 AC22 K5 NC NA NA
J7 FMC1_HPC_HA03_N LVCMOS25 AC23 K7 FMC1_HPC_HA02_P LVCMOS25 AE25
J9 FMC1_HPC_HA07_P LVCMOS25 AD23 K8 FMC1_HPC_HA02_N LVCMOS25 AE26
J10 FMC1_HPC_HA07_N LV CMOS25 AD24 K10 FMC1_HPC_HA06_P LVCMOS25 AE23
J12 FMC1_HPC_HA11_P LVCMOS25 AD20 K11 FMC1_HPC_HA06_N LVCMOS25 AF23
J13 FMC1_HPC_HA11_N LV CMOS25 AE20 K13 FMC1_HPC_HA10_P LVCMOS25 AE22
J15 FMC1_HPC_HA14_P LVCMOS25 AE18 K14 FMC1_HPC_HA10_N LVCMOS25 AF22
J16 FMC1_HPC_HA14_N LV CMOS25 AF18 K16 FMC1_HPC_HA17_CC_P LVCMOS25 AA20
J18 FMC1_HPC_HA18_P LVCMOS25 AA17 K17 FMC1_HPC_HA17_CC_N LVCM OS25 AB20
J19 FMC1_HPC_HA18_N LV CMOS25 AB17 K19 FMC1_HPC_HA21_P LVCMOS25 AB16
J21 FMC1_HPC_HA22_P LVCMOS25 Y15 K20 FMC1_HPC_HA21_N LVCM OS25 AC16
J22 FMC1_HPC_HA22_N LV CMOS25 AA15 K22 FMC1_HPC_HA23_P LVCMOS25 W14
J24 NC NA NA K23 FMC1_HPC_HA23_N LVCMOS25 W15
J25 NC NA NA K25 NC NA NA
J27 NC NA NA K26 NC NA NA
J28 NC NA NA K28 NC NA NA
J30 NC NA NA K29 NC NA NA
J31 NC NA NA K31 NC NA NA
J33 NC NA NA K32 NC NA NA
J34 NC NA NA K34 NC NA NA
J36 NC NA NA K35 NC NA NA
J37 NC NA NA K37 NC NA NA
J39 NC NA NA K38 NC NA NA
K40 NC NA NA
Notes:
1. No I/O standards are associated with MGT connections.
Table 1-26: HPC Connections, J30 to FPGA U1 (Cont’d)
J30 FMC1
HPC Pin
Schematic Net Name I/O Standard
FPGA
(U1) Pin
J30 FMC1
HPC Pin
Schematic Net Name I/O Standard
FPGA
(U1) Pin
