Xilinx VCU128 User Manual

QSFP28 Connections to Transceiver Banks 67 and 69
The following table lists the QSFP28 module level-shied control signal connecons to
XCVU37P FPGA U1 bank 67 (QSFP1, QSFP4) and bank 69 (QSFP2, QSFP3).
Table 26: XCVU37P U1 to QSFP28 Module Control and I2C Connections
FPGA (U1) Pin
Schematic Net
Name
1
,
2
FPGA (U1)
Direction
Module Pin Num Module Pin Name
QSFP1 J42 (U1 bank 67)
BM24 QSFP1_MODSKLL_LS Output 8 MODSELL
BN25 QSFP1_RESETL_LS Output 9 RESETL
BM25 QSFP1_MODPRSL_LS Output 27 MODPRSL
BP24 QSFP1_INTL_LS Input 28 INTL
BN24 QSFP1_LPMODE_LS Output 31 LPMODE
U54.13 QSFP1_I2C_SDA BiDir 12 SDA
U54.14 QSFP1_I2C_SCL Output 11 SCL
QSFP2 J39 (U1 bank 69)
BN5 QSFP2_MODSKLL_LS Output 8 MODSELL
BN6 QSFP2_RESETL_LS Output 9 RESETL
BN7 QSFP2_MODPRSL_LS Output 27 MODPRSL
BP6 QSFP2_INTL_LS Input 28 INTL
BP7 QSFP2_LPMODE_LS Output 31 LPMODE
U54.15 QSFP2_I2C_SDA BiDir 12 SDA
U54.16 QSFP2_I2C_SCL Output 11 SCL
QSFP3 J35 (U1 bank 69)
BM5 QSFP3_MODSKLL_LS Output 8 MODSELL
BL6 QSFP3_RESETL_LS Output 9 RESETL
BM7 QSFP3_MODPRSL_LS Output 27 MODPRSL
BL7 QSFP3_INTL_LS Input 28 INTL
BN4 QSFP3_LPMODE_LS Output 31 LPMODE
U54.17 QSFP3_I2C_SDA BiDir 12 SDA
U54.18 QSFP3_I2C_SCL Output 11 SCL
QSFP4 J32 (U1 bank 67)
BK23 QSFP4_MODSKLL_LS Output 8 MODSELL
BK24 QSFP4_RESETL_LS Output 9 RESETL
BL22 QSFP4_MODPRSL_LS Output 27 MODPRSL
BH21 QSFP4_INTL_LS Input 28 INTL
BH21 QSFP4_LPMODE_LS Output 31 LPMODE
U54.19 QSFP4_I2C_SDA BiDir 12 SDA
